The Cyrix-ct 12/24V-230A is a microprocessor-controlled heavy-duty relay that automatically connects batteries in parallel when one of them reaches a specific voltage (indicating it is being charged) and disconnects them when the voltage drops (indicating discharge).
Key Features:
Intelligent Voltage Monitoring: The Cyrix-ct senses the voltage trend and prevents unnecessary switching.
12V and 24V Automatic: Automatically detects the system voltage.
No Voltage Loss: Unlike diode isolators, there is no voltage drop, so alternator voltage adjustment is not required.
Prioritizes Starter Battery: Ensures the starter battery is always charged first.
Start Assist: Allows for an optional push button to parallel batteries for emergency starting.
Technical Specifications
Continuous current: 230 Amps
Peak current (5 seconds): 500 Amps
System voltage: 12V or 24V (auto-detect)
Protection class: IP54
Weight: 0.27 kg
Dimensions (hxwxd): 65 x 100 x 50 mm
