The Victron MultiPlus is a powerful pure sine wave inverter and an advanced battery charger, combined in a single compact enclosure. This unique system is designed to provide a stable and reliable power supply wherever you are.
The MultiPlus can deliver more power than your grid connection or generator allows. If the connected devices temporarily draw too much power, the output is supplemented with energy from the battery. As soon as sufficient power is available again, the surplus energy is used to recharge the battery. This prevents fuses from blowing, which is ideal for use at campsites or in harbors.
In the event of a power outage or when the generator is switched off, the MultiPlus will switch from charger to inverter mode in a fraction of a second. As a result, connected devices, such as computers and other sensitive electronics, continue to function without interruption.
To achieve a higher output power, up to six MultiPlus units can be connected in parallel. It is also possible to create a three-phase power system.
Input Voltage: 12 Volts
Output Voltage: 230 Volts
Continuous Power: 1200 VA / 1000 Watts
Peak Power: 2400 Watts
Dimensions (H x W x D): 375 x 214 x 110 mm
Weight: 10 kg
Datasheet Phoenix Inverter Compact
